J1900/J6412 IP65 Fanless Panel PC

AED 0.00
AED 0.00
Sale Availability on request
Shipping calculated at checkout.

Rugged IP65 fanless panel PC with J1900 or J6412 CPU, touch display, wide-temp support. Ideal for AGV control, machine vision, logistics.

Overview

This IP65-rated fanless panel PC runs on either Intel® J1900 or ARM-based J6412 CPUs, built for harsh environments. Its sealed front bezel blocks dust and water, while the fanless design means zero moving parts—and zero downtime. Perfect for AGV controllers, machine vision stations, and logistics terminals.

Product Description

Get reliable compute at the edge with this industrial panel PC:

  • Dual CPU Options: Choose an efficient Intel® J1900 or ARM-powered J6412

  • IP65 Protection: Fully sealed against dust and water jets

  • Fanless Thermal: Silent, maintenance-free operation in –20 °C to +60 °C

  • Capacitive Touch: 5- or 10-point multitouch display for smooth UX

  • Versatile I/O: Multiple LAN, USB, serial and GPIO for sensors & motors

  • OS Flexibility: Supports Windows 10 IoT, Ubuntu Linux or custom RTOS

Whether you’re driving an AGV fleet, inspecting parts via machine vision or tracking goods in a warehouse, this panel PC stays cool, clean and online—no cap.

Key Features

  • CPUs: Intel® Celeron J1900 or ARM Cortex-A53 J6412

  • Display: 10.1″–15.6″ capacitive touch options

  • IP65 Bezel: Dust-tight, water-jet resistant front

  • Memory & Storage: Up to 8 GB DDR3/LPDDR4 + 128 GB SSD

  • I/O Ports: 2×GigE, 4×USB, 2×RS-232/422/485, HDMI, GPIO

  • Power Input: 12–24 V DC, wide-range support

  • Operating Temp: –20 °C to +60 °C

  • Mounting: Panel or VESA bracket

Specifications

Spec Detail
CPU Options Intel® J1900 (4C, 2.0 GHz) or J6412 (4C)
RAM 2–8 GB DDR3 (J1900) or LPDDR4 (J6412)
Storage 32–128 GB SSD (SATA or eMMC)
Display Size 10.1″, 12.1″ or 15.6″ (optional)
Touch 5- or 10-point capacitive, anti-glare
Protection Rating IP65 front, IP54 full enclosure
LAN 2×2.5 GbE or 2×GigE
USB 4×USB 3.0 or 2×USB 2.0
Serial 2×RS-232/422/485
Video Out HDMI or optional DP
GPIO 8-bit digital I/O
Expansion Mini-PCIe for 4G/LTE or Wi-Fi
Power 12–24 V DC, reverse polarity protection
Temp Range –20 °C to +60 °C
Humidity 10 %–90 % RH non-condensing
Dimensions (W×H×D) 278×206×45 mm (15.6″)
Weight ~2.5 kg

Supported OS / Applications / Industries

  • OS: Windows 10 IoT, Ubuntu Linux, Yocto, custom RTOS

  • Applications: AGV control, machine vision, SCADA, HMI/PLC

  • Industries: Automation, logistics, manufacturing, warehousing

Benefits & Compatibility

  • Zero Maintenance: Fanless design avoids dust clogs

  • Harsh-Ready: IP65 bezel for wash-down and dusty sites

  • Edge-Optimized: Onboard GPIO and serial for legacy gear

  • Scalable: CPU, RAM and storage options to match your workload

  • Easy Integration: Standard VESA or panel mount

Purpose of Use

Engineered for AGV controllers needing reliable compute on the move, machine vision systems requiring a sealed HMI, and logistics terminals in dusty or wet docks. Keeps your automation smooth—vibe intact.

How to Use

  1. Cut panel opening per template.

  2. Secure panel PC with included brackets.

  3. Connect 12–24 V DC, Ethernet, sensors and I/O.

  4. Install or image your OS via USB or network share.

  5. Calibrate touch and deploy your control or vision software.

Packaging / Weight / Dimensions

  • Packaging: Foam-lined industrial box with shock protection

  • Unit Weight: ~2.5 kg

  • Box Size: 360×280×120 mm

  • Includes: Panel bracket, power cable, quick-start guide

Warranty and FAQs

Warranty: One-year limited warranty; extended support available.

FAQs
Q: Can it auto-boot on power?
A: Yes—use BIOS setting for auto power-on.
Q: Does it support PoE?
A: PoE optional via mini-PCIe network card.

Performance, Quality, Durability & Reliability

Tested for 5 g vibration, 10 g shock and salt-spray per MIL-STD-810G. Industrial-grade capacitors and conformal-coated boards ensure years of solid uptime—no cap.
