CESIPC Capacitive Touch Industrial Grade Panel Pc Waterproof Industrial PCs 1tb 32GB
Couldn't load pickup availability
Rugged IP65 panel PC with 32 GB DDR4, 1 TB NVMe SSD, 10″ PCAP touch. Fanless, waterproof, Windows/Linux ready. Zero-maintenance industrial HMI.
Overview
CESIPC’s Industrial-Grade Panel PC features a glove-friendly capacitive touchscreen, 32 GB DDR4, and a 1 TB NVMe SSD in a fully sealed IP65, fanless chassis. Pre-configured for Windows 10/11 IoT or Linux, it delivers 24/7 reliability for machine control, kiosks, and wash-down environments.
Product Description
Built on an embedded Intel® Celeron® J6412 (4 cores @1.5 GHz) or optional Core™ i3-10110U CPU, this all-in-one panel PC pairs high-sensitivity PCAP touch with 32 GB DDR4 and a blazing 1 TB M.2 NVMe SSD. The die-cast aluminum housing resists dust, high-pressure sprays, and vibration. M12-sealed I/O (2× USB 3.0, GbE LAN, RS-232/485), dual-band Wi-Fi, and Bluetooth 5.0 simplify integration. Passive cooling ensures silent, maintenance-free operation from –10 °C to +60 °C.
Key Features
-
10″ Capacitive PCAP Touch: multi-touch, glove-compatible
-
IP65-Rated, Fanless Enclosure: dustproof & washdown-proof
-
32 GB DDR4 RAM: smooth multitasking for heavy HMI loads
-
1 TB NVMe SSD: rapid boot and data access
-
CPU Options: J6412 (1.5 GHz) or Core™ i3-10110U (2.1–4.1 GHz)
-
M12-Sealed I/O: 2× USB 3.0, 1× GbE LAN, 1× RS-232/485
-
Wireless: 802.11ac Wi-Fi & Bluetooth 5.0
-
Wide-Voltage Input: 9–36 V DC with surge/reverse-polarity protection
-
Passive Cooling: zero moving parts, truly silent
Specifications
| Feature | Details |
|---|---|
| Display | 10″ IPS 1280×800 PCAP capacitive touch |
| CPU | Intel® Celeron® J6412 (4 cores/4 threads, 1.5 GHz) |
| Option: Core™ i3-10110U (2 cores/4 threads, 2.1–4.1 GHz) | |
| Memory | 32 GB DDR4 (2× 16 GB SO-DIMM) |
| Storage | 1 TB M.2 NVMe SSD |
| I/O Ports | 2× USB 3.0 (M12-sealed), 1× GbE LAN (M12), 1× RS-232/485 (M12) |
| Wireless | Wi-Fi 802.11ac; Bluetooth 5.0 |
| Power Input | 9–36 V DC, surge & reverse-polarity protection |
| Protection | IP65 front & full-body sealing |
| Operating Temp | –10 °C to +60 °C |
| Mounting | Panel-cut & VESA 75×75 mm brackets |
| Dimensions | 273×188×55 mm (W×H×D) |
| Weight | ~2.5 kg |
Supported OS / Applications / Industries
-
OS: Windows 10/11 IoT, Linux (Ubuntu/Debian)
-
Apps: HMI, SCADA, data acquisition, kiosk control
-
Industries: Manufacturing, food & beverage, water treatment, logistics
Benefits & Compatibility
-
Zero-Maintenance: fanless avoids clogging & noise
-
Wash-Down Ready: IP65 seals withstand cleaning sprays
-
Glove-Operable Touch: precise PCAP input under PPE
-
High-Capacity Storage: 1 TB SSD for logs & media
-
Robust Connectivity: sealed I/O plus wireless options
Purpose of Use
Ideal for machine-side operator panels, wash-down production floors, outdoor kiosks, and any application needing a waterproof, high-performance touch PC.
How to Use
-
Cut panel opening per supplied template
-
Secure with panel clamps or VESA brackets
-
Connect 9–36 V DC, network, USB/serial, and antenna
-
Boot into Windows IoT or Linux; install your HMI/SCADA software
-
Clean front with low-pressure water spray—no fans to service
Stock Availability
In stock: J6412 base models. Core™ i3 upgrades ship in 5–7 days. Contact sales@neotech.ae for live inventory.
Pricing (Starting at)
– AED 4,500 (J6412, 32 GB, 1 TB)
Volume discounts & custom quotes: sales@neotech.ae
Warranty & FAQs
Warranty: 1 year standard; extensions to 3 years available.
FAQs:
-
Can I wash it daily? Yes—IP65 protects against jets and dust.
-
Does touch work with gloves? Absolutely—PCAP supports light-glove operation.
After-Sales Support
24/7 remote diagnostics, firmware updates, and optional on-site service keep you running.
Get in Touch
Questions or custom configs? Email sales@neotech.ae for expert assistance.
Disclaimer
Specifications subject to change without notice. Images are illustrative—verify details with our sales team prior to purchase.
