7–24″ Linux & Windows Industrial All-in-One Touch Panel PC

AED 0.00
AED 0.00
Sale Availability on request
Shipping calculated at checkout.

Shop rugged 7–24″ AIO touch panel PC: Windows 10/11 & Linux, fanless, IP65 front, dual LAN, USB/COM, VESA mount. Fast UAE shipping—order now!

Overview

From compact 7″ kiosks to 24″ HMI stations, this all-in-one touch panel PC handles Windows 10/11 or Linux. Fanless, IP65 front-bezel, and rich I/O make it ideal for factory floors, control rooms, and outdoor kiosks. Zero-maintenance design keeps you running 24/7, no cap.

Product Description

This embedded PC combines display, compute, and I/O in a sealed metal housing. Choose your size—7″/10″/12″/15″/21.5″/24″ IPS touchscreen—and your OS: Windows 10/11 IoT or Ubuntu LTS. Conduction cooling means no fans or filters. Dual Gigabit LAN, 4× USB 3.0 & 2.0, HDMI, 2× RS-232/422/485, and isolated GPIO connect to sensors, PLCs, and cameras. Wide-range 9–36 V DC input with surge protection suits vehicle or solar power. Mount via panel cutout, VESA, or DIN-rail.

Key Features

  • Screen Sizes: 7″–24″ IPS, 300–500 nits, 5-point capacitive touch

  • OS Support: Windows 10/11 IoT & Ubuntu Linux

  • Fanless & IP65 Front: dust/water-jet proof, zero-maintenance

  • Rich I/O: 2× GigE LAN, 4× USB 3.0, 2× USB 2.0, HDMI, 2× COM, GPIO

  • Power Input: DC 9–36 V with surge/reverse protection

  • Compute Options: Intel Celeron to Core i7 (U-series) or ARM SoCs

  • Mounting: panel-mount, VESA 75/100 mm, DIN-rail kits

Specifications

Feature Details
Display 7″/10″/12″/15″/21.5″/24″ IPS, 1280×800–1920×1080, 300–500 nits, multi-touch
CPU Options Intel Celeron N5105 / i3-10110U / i5-10210U / i7-10510U or ARM Cortex-A53 variants
Memory 4–16 GB DDR4/LPDDR4
Storage 32–256 GB eMMC/SSD + microSD slot
LAN Dual Gigabit RJ45
USB 4× USB 3.0, 2× USB 2.0
Serial 2× RS-232/422/485
GPIO 4-in, 4-out isolated
Video Out HDMI 1.4 (up to 4K@30 Hz on larger panels)
Power Input 9–36 V DC, 60 W max, surge & reverse protection
Ruggedness IP65 front bezel, IP40 rear, –20 °C to +60 °C
Operating System Windows 10/11 IoT, Ubuntu 18.04/20.04 LTS
Dimensions Varies by size; depth ~50 mm
Mounting Options Panel cutout, VESA 75/100 mm, DIN-rail
Weight 1.2–5 kg depending on panel size

Supported OS / Applications / Industries

  • OS: Win 10/11 IoT, Ubuntu Linux

  • Industries: Manufacturing HMI/SCADA, food & beverage, outdoor kiosks, transportation, energy

  • Use Cases: real-time monitoring, process control, digital signage, machine vision, access control

Benefits & Compatibility

  • Maintenance-Free: fanless, no filter changes

  • All-Weather: IP65 front handles wash-down & dust

  • Flexible Power: works on vehicle/solar 9–36 V DC

  • Universal I/O: integrates legacy serial and modern USB devices

  • Easy Deployment: multiple mounting options for any environment

Purpose of Use

Ideal for building interactive control panels, outdoor self-service kiosks, conveyor control HMI, and mobile test stations—where uptime and reliability are non-negotiable.

How to Use

  1. Panel-mount or install via VESA/DIN-rail kit.

  2. Connect 9–36 V DC power, LAN, and peripherals.

  3. Boot into your chosen OS and install apps.

  4. Calibrate touch via OSD menu.

  5. Run 24/7—no fans to fail.

Pro tip: Enable BIOS watchdog for auto-reboot on system faults.

Packaging / Weight / Dimensions

  • Includes: Panel PC unit, power cable, mounting brackets, quick-start guide

  • Carton Size: varies by panel; industrial-grade packaging

  • Packed Weight: 1.5–6 kg depending on size

Warranty and FAQs

Warranty: 2-Year Industrial Warranty
FAQs:

  • Q: Can I switch OS?
    A: Yes—dual-boot or single install of Windows or Linux.

  • Q: Is glove-touch supported?
    A: Yes—enable glove mode in OSD.

  • Q: How do I access COM ports?
    A: Use rear panel connectors; jumper-configurable serial modes.

Visit our Support Center.

Performance, Quality, Durability, and Reliability

MIL-STD-810G certified for shock and vibration. Conduction-cooled design keeps temps < 85 °C under full load. MTBF > 50 000 hrs in industrial environments.
