Portable 1-Inch Coding for Larger Text, Barcodes, QR Codes and Variable Product Information.

BENTSAI BT-HH6210B 6210B Portable Handheld Inkjet Printer The BENTSAI BT-HH6210B is a portable 1-inch thermal inkjet printer designed for handheld product coding, packaging identification and variable-data marking.

Its key difference from the smaller BT-HH6205B is its larger 25.4 mm / 1-inch printhead, allowing larger characters and multi-line content while retaining a portable handheld format.

BENTSAI documents support for text, numbers, dates, counters, images, logos, 1D barcodes, QR codes, Data Matrix and variable data.

Overview

The BT-HH6210B is designed for businesses requiring portable coding without permanently installing a printer on a production line.

Key characteristics include:

• 25.4 mm / 1-inch printhead
• Adjustable character/print height within the supported range
• Up to 10 lines according to BENTSAI's 6205/6210 series specification
• 300 dpi print resolution
• Handheld operation
• Text and number printing
• Date and time coding
• Batch and lot coding
• Serial numbers and counters
• 1D barcode printing
• QR Code
• Data Matrix
• GS1 Data Matrix listed by BENTSAI
• Image and logo printing
• Variable-data printing
• USB interface
• Water-based and solvent-based ink cartridge options

25.4mm / 1-Inch Print Height

The main reason to choose the BT-HH6210B instead of a 12.7 mm model is its larger printing area.

Maximum Print Height: 25.4 mm / 1 inch

BENTSAI's current series documentation specifies the 6210 models at approximately 2.5–25.4 mm with 1–10 lines, while its retail listing describes a broader adjustable character range beginning at 0.8 mm. Because these two manufacturer sources differ slightly, NEOTECH® should conservatively describe the printer as supporting up to 25.4 mm print height rather than guaranteeing the minimum character height for every layout.

This larger printhead can be useful for:

• Larger product identification
• Outer carton coding
• Batch numbers
• Lot numbers
• Production information
• Date information
• Large QR codes
• Barcodes
• Logos
• Multi-line text
• Warehouse identification

Print Resolution

Resolution: 300 dpi

The 6210 platform is designed around the larger 25.4 mm print area, whereas the smaller 6205 series provides 300/600 dpi options.

BENTSAI specifies a maximum print speed of up to 30 m/min for the 6210 series. This is a manufacturer-rated maximum and should not be represented as a guaranteed real-world handheld speed.

Variable Data Printing

The BT-HH6210B supports variable information rather than being limited to fixed text.

Possible content includes:

• Sequential numbers
• Serial numbers
• Batch numbers
• Dates
• Counters
• Variable text
• Variable barcodes
• Variable QR codes
• Variable Data Matrix codes

This can make the printer relevant for product identification and traceability workflows where printed information changes between items or batches.

Barcode & 2D Code Printing

BENTSAI's current 6205/6210 documentation lists support for:

1D Barcodes

• Code 128
• Code 39
• EAN-8
• EAN-13
• UPC-A
• UPC-E
• ITF 2 of 5
• ITF-14

2D Codes

• QR Code
• Data Matrix
• GS1 Data Matrix

For regulated GS1, logistics or traceability applications, the final code structure and readability should be validated for the customer's specific system.

Image & Logo Printing

Supported image formats documented by BENTSAI include:

• JPG
• JPEG
• PNG
• BMP

This allows suitable monochrome graphics and logos to be incorporated into print layouts.

Water-Based & Solvent-Based Ink Options

The correct ink cartridge should be selected according to the material being marked.

Water-Based Ink

BENTSAI identifies water-based cartridges for porous and semi-porous substrates such as compatible:

• Paper
• Corrugated cartons
• Wood
• Fiberboard
• Textile

Solvent-Based Ink

BENTSAI identifies solvent-based cartridges for selected semi-porous and non-porous substrates including compatible:

• Plastic
• Glass
• Metal
• Aluminium foil
• Cable

Important Material Compatibility Guidance

The statement that a printer can print on a category of material does not mean every surface within that category will produce the same result.

Ink adhesion and drying can be affected by:

• Surface coating
• Surface energy
• Material composition
• Oil or contamination
• Dust
• Ink formulation
• Temperature
• Printing distance
• Required abrasion resistance

For critical applications, testing the intended cartridge on the actual material before production use is recommended.

Ink Colours

BENTSAI currently documents multiple cartridge colours across the 6205/6210 platform.

Depending on water-based or solvent-based cartridge selection, options may include:

• Black
• Cyan
• Magenta
• Yellow
• Green
• White
• Invisible ink

Exact colour availability should be confirmed before ordering because not every colour is necessarily offered in every ink formulation or regional configuration.

Packaging & Carton Coding Applications

The 25.4 mm printing area makes the BT-HH6210B particularly relevant for larger packaging.

Potential applications include:

• Corrugated carton coding
• Outer box marking
• Product identification
• Batch numbers
• Lot numbers
• Date codes
• Serial numbers
• QR codes
• Barcodes
• Shipping-related identification
• Variable production information

Manufacturing Applications

The printer may also be considered for compatible:

• Component identification
• Production codes
• Batch tracking
• Product references
• Internal traceability
• Serial-number marking
• Logo printing

Suitability depends on the substrate, ink and required durability.

Warehouse & Logistics Applications

Potential uses include:

• Carton identification
• Inventory codes
• Product references
• Internal tracking numbers
• QR identification
• Variable barcodes
• Large-character box marking

The printer itself does not provide warehouse-management or inventory software.

Technical Specifications

Brand: BENTSAI

Model: BT-HH6210B / HH6210B

Series: 6210

Product Type: Portable Handheld Thermal Inkjet Printer

Printhead: 25.4 mm / 1 inch

Maximum Print Height: 25.4 mm

Print Lines: Up to 10 according to BENTSAI series documentation

Print Resolution: 300 dpi

Maximum Print Size: 25.4 × 406 mm according to BENTSAI series documentation

Manufacturer-Rated Maximum Print Speed: Up to 30 m/min

Printing Technology: Thermal Inkjet

Operating Mode: Handheld only

Supported Content: Text, numbers, images, logos, 2D codes, barcodes, dates, counters and variable/database content

Image Formats: JPG, JPEG, PNG, BMP

Fonts: TrueType and dot-matrix fonts

Interface: USB

Power Input: DC 5V / 2A according to BENTSAI's current series specification

Ink Throw Distance: Approximately 2–5 mm

Ink Options: Water-based / solvent-based, depending on substrate

BENTSAI's current manufacturer series page lists approximately 126 × 43 × 206 mm and 420 g for the B-version platform, while its retail listing gives slightly different dimensional and weight figures. Because manufacturer pages currently differ, these physical specifications should be confirmed against the supplied unit before publication as guaranteed values.

Battery Operation

BENTSAI's retail specification describes the BT-HH6210B with rechargeable battery operation and states up to 16 hours of working time.

Actual battery life can vary according to:

• Printing frequency
• Print coverage
• Screen usage
• Battery age
• Ambient conditions
• Operating configuration

Therefore, NEOTECH® should describe this as a manufacturer-stated maximum, not a guaranteed operating duration.

Purpose of Use

The BT-HH6210B is intended for portable direct coding where the operator manually moves the printer across the product or packaging.

Typical workflow:

Create Message → Select Correct Ink → Position Printer → Move Across Surface → Print

It is particularly useful when an item is too large, heavy or inconvenient to move to a fixed coding station.

BT-HH6210B vs BT-HH6205B

BT-HH6205B

Printhead: 12.7 mm / 0.5 inch
Resolution: 300 / 600 dpi
Lines: Up to 5
Operation: Handheld
Best considered for: Smaller text and compact coding

BT-HH6210B

Printhead: 25.4 mm / 1 inch
Resolution: 300 dpi
Lines: Up to 10
Operation: Handheld
Best considered for: Larger characters, multi-line information, cartons and larger markings

BT-HH6210B vs BT-HH6210BL

This distinction is important.

BT-HH6210B

• Handheld operation
• USB interface
• 25.4 mm printhead
• Designed for manually operated portable coding

BT-HH6210BL

• Handheld operation
• Inline/conveyor capability
• External sensor interface
• 25.4 mm printhead
• Can be configured for sensor-triggered conveyor coding

BENTSAI explicitly identifies the 6210B as handheld-only and the 6210BL as handheld + inline.

Therefore, we should not advertise the BT-HH6210B as a conveyor printer.

Buyer Guidance

Before ordering, confirm:

• BT-HH6210B is the required model
• 25.4 mm print height requirement
• Required number of print lines
• Required character size
• Barcode format
• QR / Data Matrix requirement
• Variable-data requirement
• Substrate material
• Porous or non-porous surface
• Water-based or solvent-based ink
• Required ink colour
• Required print durability
• Handheld-only operation is acceptable

If automatic conveyor printing is required, consider the BT-HH6210BL instead.

Why Choose NEOTECH® UAE

NEOTECH® can assist customers in understanding:

• 6205 vs 6210 print-height requirements
• 6210B vs 6210BL operating modes
• 12.7 mm vs 25.4 mm printing
• Water-based vs solvent-based ink
• Porous vs non-porous substrate considerations
• Barcode and QR requirements
• Handheld vs production-line coding
• UAE product availability

Learn First. Decide Second. Buy Only If It Is Right for Your Needs.

There is absolutely no obligation or pressure to proceed with the purchase with us.

UAE Delivery

NEOTECH® supplies within the United Arab Emirates.

Shipping: Free Standard Shipping
Order Cut-Off: 2:00 PM GST
Handling: 1–2 business days
Transit: 3–5 business days
Estimated Total Delivery: 4–7 business days

Stock and the exact ink cartridge configuration should be confirmed before time-sensitive orders.

FAQ - BENTSAI BT-HH6210B

Q: What is the maximum print height of the BENTSAI BT-HH6210B?
A: The BT-HH6210B uses a 25.4 mm / 1-inch printhead. BENTSAI's current series documentation specifies up to 25.4 mm print height and up to 10 lines, depending on the content and configuration.

Q: Can the BENTSAI BT-HH6210B print QR codes, Data Matrix and barcodes?
A: Yes. BENTSAI documents QR Code, Data Matrix, GS1 Data Matrix and multiple common 1D barcode formats, together with text, dates, counters, images and variable data.

Q: Can the BT-HH6210B be installed on a conveyor line?
A: The BT-HH6210B is documented as the handheld-only model. For handheld plus sensor-triggered inline/conveyor operation, BENTSAI identifies the BT-HH6210BL as the appropriate variant.
