Modular Windows Computing for Field, Utility, Vehicle and Operational Environments.

Panasonic TOUGHBOOK 40 Mk1 – 14-Inch Rugged Windows Notebook | The Panasonic TOUGHBOOK 40 Mk1 is a 14-inch rugged Windows notebook designed for field and mobile computing environments where physical protection, modular expansion and multiple connectivity options are important.

According to Panasonic's attached TOUGHBOOK 40 Mk1 specification sheet, the standard configuration includes an Intel Core i5-1145G7 vPro processor, Windows 11 Pro, 16GB DDR4 RAM, 512GB NVMe OPAL SSD and a 14-inch HD touchscreen.

The platform also supports optional expansion for mobile broadband, GPS, additional storage, authentication and interface requirements.

Overview

Panasonic designed the TOUGHBOOK 40 Mk1 around a modular architecture with multiple configurable expansion areas.

The attached Panasonic datasheet identifies key platform characteristics including:

• 14-inch HD touchscreen
• Intel Core i5-1145G7 vPro standard
• Intel Core i7-1185G7 vPro optional
• Windows 11 Pro
• 16GB DDR4 RAM standard
• Up to 64GB RAM supported
• 512GB quick-release NVMe OPAL SSD
• Wi-Fi 6
• Bluetooth 5.1
• Optional 4G or 5G with eSIM
• Optional dedicated GPS
• IP66 ingress protection
• MIL-STD-810H testing
• 180 cm drop testing
• Modular expansion areas
• Magnesium casing with integrated carry handle

These are Mk1 platform specifications and should not be mixed with newer TOUGHBOOK 40 Mk2 configurations.

14-Inch HD Touch Display

Panasonic specifies the TOUGHBOOK 40 Mk1 with:

Display Size: 14 inches
Resolution: 1920 × 1080 pixels
Panel: Active Matrix TFT colour touch LCD
Brightness: Up to 1,200 cd/m²

The display format can be useful for field applications involving:

• Technical drawings
• Inspection forms
• Diagnostic applications
• Mapping
• Enterprise applications
• Maintenance records
• Vehicle-based workflows

Panasonic also notes that display characteristics can vary within normal manufacturing tolerances.

Processor Platform

The standard TOUGHBOOK 40 Mk1 configuration documented by Panasonic uses:

Intel Core i5-1145G7 vPro
1.1 GHz base frequency, up to 4.4 GHz

Panasonic also lists an optional:

Intel Core i7-1185G7 vPro
1.2 GHz base frequency, up to 4.8 GHz

The exact processor should therefore be confirmed for the specific unit or part number being purchased.

Memory & Storage

The Mk1 specification sheet identifies:

Standard Memory: 16GB DDR4 RAM
Maximum Memory: Up to 64GB

Standard Storage: 512GB quick-release NVMe OPAL SSD with heater

Panasonic also references optional storage configurations up to 2TB within the TOUGHBOOK 40 platform.

Storage and RAM should be verified against the exact configuration rather than assumed from the family name alone.

Windows 11 Pro

The attached Panasonic document specifies:

Windows 11 Pro 64-bit

A Windows 10 Pro downgrade model was also listed as an optional configuration at the time of the Mk1 datasheet.

This makes the TOUGHBOOK 40 Mk1 relevant to organisations requiring conventional Windows desktop applications in field environments.

Wi-Fi 6 & Bluetooth 5.1

Panasonic lists:

Wireless LAN: Intel Wi-Fi 6 AX201
Bluetooth: Bluetooth 5.1 Class 1

These wireless technologies provide connectivity for compatible enterprise networks and peripherals.

Actual wireless performance depends on the surrounding infrastructure, access points, interference and connected devices.

Optional 4G & 5G Mobile Broadband

The Mk1 platform supports optional mobile broadband.

Panasonic's specification sheet lists:

4G LTE: EM7690 with eSIM support

5G: EM9190 with eSIM support

Mobile connectivity is optional and should not be assumed to be included with every TOUGHBOOK 40 Mk1 unit.

Optional Global Positioning

Panasonic also lists an optional u-blox NEO-M8J positioning module supporting:

• GPS
• GLONASS
• Beidou
• Galileo

Dedicated positioning hardware should be confirmed for the exact configuration before ordering.

Rugged Construction

Panasonic documents the TOUGHBOOK 40 Mk1 with:

Ingress Protection: IP66

Drop Resistance: 180 cm

Testing Standard: MIL-STD-810H / IEC 60529 testing through an independent third-party laboratory

Operating Temperature: -29°C to +63°C

Chassis: rugged magnesium casing with carry handle

These figures relate to specific test conditions and should not be interpreted as meaning the notebook is indestructible, waterproof under all circumstances or suitable for every hazardous environment.

Modular Expansion Areas

One of the defining characteristics of the TOUGHBOOK 40 platform is its configurable expansion architecture.

The Mk1 datasheet identifies:

Left Expansion Area

• Second SSD
• Smart Card Reader
• DVD Multi Drive
• Blu-ray Drive

Right Expansion Area

• Second battery
• Smart Card Reader

Rear Expansion Area

• VGA + RS-232 + second native LAN
• USB + RS-232 + second HDMI
• Dual USB + second HDMI

Palm Rest Expansion Area

• Fingerprint reader
• Multi-user fingerprint authentication
• Contactless smart card reader

Not all options can be installed simultaneously. Exact configuration must be confirmed before purchase.

Standard Interfaces

Panasonic documents the TOUGHBOOK 40 Mk1 with interfaces including:

USB 3.2 Gen 1 Type-A: 2
Thunderbolt 4: 1
MicroSDXC: 1
HDMI: 1
Headset: 1
DC Input: 1
Port Replicator: 1
Quad Path Through Connector: 1
Gigabit Ethernet: Standard
Second Ethernet: Optional

This interface flexibility is relevant for field equipment that must connect to different peripherals or docking environments.

Security Features

The Panasonic datasheet lists:

• TPM 2.0
• Password security
• Hardware security lock slot
• Quick-release OPAL SSD
• Optional Windows Hello fingerprint reader
• Optional contactless smart card reader
• Optional 5MP IR camera with privacy shutter

Security effectiveness depends on the organisation's complete hardware, operating-system and IT-policy configuration.

Battery & Hit-Swap Capability

Panasonic specifies a standard lithium-ion battery rated at:

10.8V
6500 mAh typical
6300 mAh minimum

The datasheet lists approximately 18 hours of battery operation under MobileMark 2014 testing and approximately 36 hours with a second battery.

Hit-swap functionality is listed when the optional second battery is installed.

Actual runtime varies according to workload, screen brightness, wireless connectivity, installed hardware, battery condition and environmental conditions.

Technical Specifications

Brand: Panasonic

Product Family: TOUGHBOOK

Model Family: TOUGHBOOK 40 Mk1

Product Type: Rugged Windows Notebook

Standard Processor: Intel Core i5-1145G7 vPro

Optional Processor: Intel Core i7-1185G7 vPro

Operating System: Windows 11 Pro 64-bit

Memory: 16GB DDR4 standard

Maximum Memory: 64GB

Storage: 512GB quick-release NVMe OPAL SSD standard

Display: 14-inch Active Matrix Touch LCD

Resolution: 1920 × 1080 Full HD

Brightness: Up to 1,200 cd/m²

Graphics: Intel UHD; Intel Iris Xe supported with two RAM modules according to Panasonic

Wi-Fi: Intel Wi-Fi 6 AX201

Bluetooth: 5.1 Class 1

Ethernet: Gigabit Ethernet

Mobile Broadband: Optional 4G LTE / 5G with eSIM

GPS: Optional u-blox NEO-M8J

Thunderbolt: Thunderbolt 4

USB: 2 × USB 3.2 Gen 1 Type-A

HDMI: 1

Memory Card: microSDXC

Security: TPM 2.0 and additional configurable security options

IP Rating: IP66

Drop Test: 180 cm

Operating Temperature: -29°C to +63°C

Dimensions: 354 × 301 × 54.4 mm, excluding protruding parts

Weight: Approximately 3.35 kg

These specifications are taken from the attached TOUGHBOOK 40 Mk1 Spec Sheet dated 24 May 2022.

Field Service & Utility Applications

The TOUGHBOOK 40 Mk1 can be considered for field environments involving:

• Utilities
• Field maintenance
• Infrastructure inspection
• Transportation
• Vehicle-based computing
• Technical service
• Mobile workforce applications
• Industrial maintenance
• Outdoor operational work

Panasonic specifically positions the platform for demanding field environments including Defence, Police and Utilities in the attached documentation.

Vehicle & Mobile Operations

Panasonic notes that the TOUGHBOOK 40 platform is designed with shock and vibration protection for vehicle docking.

This can make it relevant for mobile deployments involving:

• Fleet vehicles
• Field-service vehicles
• Utility vehicles
• Mobile workstations
• Vehicle diagnostics

Docking hardware and vehicle power requirements should be checked separately for the exact installation.

Purpose of Use

The Panasonic TOUGHBOOK 40 Mk1 is intended for organisations that require a complete Windows notebook in working environments where physical protection, replaceable components, modular interfaces and optional mobile connectivity are important.

It is not necessary to select a rugged notebook simply because it has higher protection specifications. The decision should be based on the real operating environment, application requirements and total deployment needs.

Mk1 vs Mk2 – Important Buyer Guidance

The TOUGHBOOK 40 Mk1 should not be confused with newer TOUGHBOOK 40 Mk2 configurations.

This attached Mk1 specification uses:

11th Gen Intel Core processors
DDR4 memory
Intel Wi-Fi 6 AX201
Bluetooth 5.1

Newer Mk2 configurations can use different processors, memory generations, wireless hardware and exact specifications.

Always verify the complete Panasonic model or manufacturer part number before ordering.

Things to Verify Before Ordering

Before purchasing a TOUGHBOOK 40 Mk1 configuration, confirm the exact:

• Panasonic part number
• Processor
• RAM
• SSD
• Windows edition
• Keyboard layout
• 4G / 5G requirement
• GPS requirement
• Camera requirement
• Second battery requirement
• Expansion modules
• Smart-card or fingerprint requirements
• Docking hardware
• Vehicle-mounting requirement
• Included accessories

Because the TOUGHBOOK 40 is highly configurable, the family name alone is not enough to identify the complete hardware specification.

Why Choose NEOTECH® UAE

NEOTECH® provides product-level guidance for rugged mobile computing requirements.

We can help customers review:

• TOUGHBOOK family selection
• Mk1 versus Mk2 identification
• Exact Panasonic part numbers
• Processor and memory requirements
• Mobile broadband requirements
• Expansion-module requirements
• Docking and field accessories
• Windows application requirements

Learn First. Decide Second. Buy Only If It Is Right for Your Needs.

There is absolutely no obligation or pressure to proceed with the purchase with us.

UAE Delivery

NEOTECH® supplies within the United Arab Emirates.

Shipping: Free Standard Shipping
Order Cut-Off: 2:00 PM GST
Handling: 1–2 business days
Transit: 3–5 business days
Estimated Total Delivery: 4–7 business days

Availability should be confirmed for the required TOUGHBOOK 40 Mk1 configuration before a time-sensitive order.

FAQ - Panasonic TOUGHBOOK 40 Mk1

Q: What processor does the Panasonic TOUGHBOOK 40 Mk1 use?
A: The attached Panasonic Mk1 specification lists the Intel Core i5-1145G7 vPro as the standard processor and the Intel Core i7-1185G7 vPro as an optional configuration.

Q: Does the TOUGHBOOK 40 Mk1 support 5G and GPS?
A: Panasonic lists optional 4G LTE and 5G mobile broadband with eSIM support, along with optional dedicated positioning supporting GPS, GLONASS, Beidou and Galileo. These features are configuration-dependent and are not included on every unit.

Q: What is the difference between TOUGHBOOK 40 Mk1 and Mk2?
A: The attached Mk1 specification is based on 11th-generation Intel Core processors, DDR4 memory, Wi-Fi 6 and Bluetooth 5.1. Mk2 is a newer generation with different processor and platform configurations, so Mk1 and Mk2 specifications should not be mixed.
