Rugged IP65 10″ fanless panel PC, Intel® Core™ i5-1235U, Windows 10/11 IoT ready. Capacitive touch, Advantech-class reliability, zero-maintenance HMI.
Overview
The CESIPC 10″ IP65 Embedded Panel PC pairs 12th-Gen Intel® Core™ i5-1235U performance with a sealed, fan-free chassis. Its glove-compatible PCAP touchscreen and Advantech-grade build deliver reliable, maintenance-free HMI for control rooms, kiosks, and wash-down zones—running Windows 10/11 IoT or Linux seamlessly.
Product Description
At its heart is the Intel® Core™ i5-1235U (10 cores: 2P+8E, up to 4.4 GHz), backed by 8 GB DDR4 RAM and a 256 GB M.2 NVMe SSD (upgradeable to 1 TB). The IP65-rated die-cast aluminum housing resists dust and water jets. A high-sensitivity 10.1″ PCAP capacitive touchscreen works with gloves. M12-sealed I/O (2× USB 3.0, GbE LAN, RS-232/485), dual-band Wi-Fi, and Bluetooth 5.2 round out connectivity. Passive cooling ensures silent 24/7 uptime from –10 °C to +60 °C on 9–36 V DC power.
Key Features
-
12th-Gen Core™ i5-1235U: 10 cores/12 threads, up to 4.4 GHz
-
IP65-Sealed Fanless Chassis: wash-down and dust-proof, zero maintenance
-
10.1″ Capacitive Touch: PCAP multi-touch, glove-compatible
-
8 GB DDR4 & 256 GB NVMe SSD: responsive multitasking & fast boot
-
M12-Sealed I/O: 2× USB 3.0, 1× GbE LAN, 1× RS-232/485
-
Wireless: Wi-Fi 6 (802.11ax) & Bluetooth 5.2
-
Passive Cooling: truly silent, no moving parts
-
Wide-Voltage Input: 9–36 V DC with surge & reverse-polarity protection
Specifications
| Feature |
Details |
| Display |
10.1″ IPS 1280×800 PCAP capacitive touchscreen |
| CPU |
Intel® Core™ i5-1235U (2P + 8E, 1.3–4.4 GHz, 12 threads) |
| Memory |
8 GB DDR4 |
| Storage |
256 GB M.2 NVMe SSD (upgradeable to 1 TB) |
| I/O Ports |
2× USB 3.0; 1× GbE LAN; 1× RS-232/485 (all M12-sealed) |
| Wireless |
Wi-Fi 6 (802.11ax); Bluetooth 5.2 |
| Power Input |
9–36 V DC w/ surge & reverse-polarity protection |
| Protection |
IP65 front & full-body sealing |
| Operating Temp |
–10 °C to +60 °C |
| Mounting |
Panel-cut & VESA 75×75 mm brackets |
| Dimensions |
278×186×42 mm (W×H×D) |
| Weight |
~1.8 kg |
Supported OS / Applications / Industries
-
OS: Windows 10/11 IoT Enterprise, Linux (Ubuntu/Debian)
-
Applications: HMI, SCADA, kiosks, machine control
-
Industries: Manufacturing, food & beverage, water treatment, logistics
Benefits & Compatibility
-
Zero-Maintenance: fanless design avoids clogging & noise
-
Wash-Down Ready: IP65 seals handle daily cleaning
-
Glove-Operable: PCAP supports precise input even with PPE
-
Enterprise-Grade: Advantech-style reliability & longevity
-
Robust Connectivity: sealed I/O plus Wi-Fi 6 & BT 5.2
Purpose of Use
Ideal as an operator interface on CNC machines, wash-down production lines, outdoor kiosks, and any application demanding a sealed, high-performance touch computer.
How to Use
-
Cut panel opening per supplied template
-
Secure with panel clamps or VESA bracket
-
Connect 9–36 V DC, network, USB/serial, and antenna
-
Boot into Windows IoT or Linux; deploy your HMI/SCADA software
-
Clean front with low-pressure water spray—no fans to service
Stock Availability
In stock: base J6412 models. Core™ i5 configurations ship in 3–5 days. Contact sales@neotech.ae for live inventory.
Pricing (Starting at)
– AED 4 950 (i5-1235U, 8 GB, 256 GB SSD)
Volume discounts & custom quotes: sales@neotech.ae
Warranty & FAQs
Warranty: 1 year standard; extensions to 3 years available.
FAQs:
After-Sales Support
24/7 remote diagnostics, firmware updates, and optional on-site service maximize uptime.
Get in Touch
Questions or custom configurations? Email sales@neotech.ae for expert assistance.
Disclaimer
All specs subject to change without notice. Images are illustrative—verify details with our sales team prior to purchase.
