Flexible 1D & 2D Data Capture with USB, 2.4 GHz Wireless and Bluetooth Connectivity.

DS6510B / PT-R6510B Wireless 1D & 2D Barcode Scanner The DS6510B is a handheld 2D barcode scanner designed for retail, warehouse, logistics, inventory and general business data-capture applications.

It combines a CMOS imaging engine with three communication methods:

• USB wired connection
• 2.4 GHz wireless connection
• Bluetooth 4.2

The scanner can read compatible 1D and 2D barcodes from printed labels and electronic displays, including commonly used formats such as QR Code, Data Matrix and PDF417. Current DS6510B listings also identify a charging stand as part of the wireless scanner configuration.

Original model: DS6510B / DS6510B-2D
OEM / alternate product reference: PT-R6510B

The PT-R6510B reference should be verified on the actual supplied unit, packaging or supplier documentation before ordering.

Overview

Wireless barcode scanning can be useful where the operator needs to move away from the workstation while continuing to capture barcode data.

The DS6510B supports both short-range Bluetooth connectivity and dedicated 2.4 GHz wireless communication through a compatible receiver.

This makes it suitable for applications such as:

• Warehouse inventory
• Goods receiving
• Retail checkout
• Stock counting
• Logistics
• Order processing
• Product identification
• Asset inventory
• Dispatch operations

The appropriate wireless mode depends on the host device and operating environment.

Key Features

• Handheld 1D and 2D barcode scanner
• CMOS image sensor
• 640 × 480 imaging resolution
• USB wired communication
• 2.4 GHz wireless communication
• Bluetooth 4.2
• Charging stand
• Manual trigger scanning
• Auto-sensing mode
• Continuous scanning mode
• Rechargeable battery
• Offline/storage mode supported on documented DS6510B configurations
• Reads barcodes from printed labels and compatible electronic screens
• Suitable for retail, warehouse and logistics workflows

Important: 2.4 GHz Wireless Is Not Wi-Fi

Some supplier listings describe this scanner as a “2.4G Wi-Fi scanner.”

That terminology can be misleading.

The DS6510B uses a dedicated 2.4 GHz wireless connection through a compatible receiver/dongle. This should not automatically be described as connection to a conventional Wi-Fi network or router.

For accurate product information, NEOTECH® describes the interfaces as:

USB + 2.4 GHz Wireless + Bluetooth 4.2

rather than “Wi-Fi scanner.”

2D CMOS Scanning

The DS6510B uses a CMOS imaging engine rather than a traditional single-line laser mechanism.

Documented specifications include:

Sensor: CMOS
Image Resolution: 640 × 480

An area-imaging scanner can capture both conventional 1D barcodes and supported 2D symbols.

Supported Barcode Types

Documented DS6510B configurations support common barcode families including:

1D Barcodes

• UPC-A
• UPC-E
• EAN-8
• EAN-13
• Code 128
• GS1-128
• Code 39
• Code 93
• Code 11
• Interleaved 2 of 5
• Matrix 2 of 5
• Codabar
• MSI
• GS1 DataBar

2D Barcodes

• QR Code
• Micro QR
• Data Matrix
• PDF417
• Micro PDF417
• Aztec
• MaxiCode
• Han Xin Code

Exact symbology support can vary by firmware or production configuration, so specialised barcode requirements should be confirmed before deployment.

Scan From Paper & Screens

The CMOS imaging system is designed to read compatible barcodes from several media types, including:

• Printed labels
• Product packaging
• Paper documents
• Computer screens
• Tablet displays
• Smartphone screens

Screen-reading performance depends on display brightness, barcode size, contrast and viewing conditions.

Wireless Connectivity

2.4 GHz Wireless

The scanner can communicate through a compatible 2.4 GHz wireless receiver.

DS6510B documentation commonly identifies transmission distances of up to approximately 100 metres under open, unobstructed conditions.

Actual range will normally be lower indoors and depends on:

• Walls
• Shelving
• RF interference
• Building structure
• Receiver location
• Other wireless equipment

Bluetooth 4.2

Bluetooth 4.2 provides another wireless connection method for compatible host devices.

Supplier specifications describe approximately 30 metres under open conditions for Bluetooth communication.

Actual range depends on the host device and environment.

USB

A USB connection can be used where a wired connection is preferred.

This can also provide a useful alternative where wireless communication is unnecessary or restricted.

Scanning Modes

Depending on configuration and settings, documented DS6510B operation includes:

• Manual trigger mode
• Auto-sensing mode
• Continuous scan mode

This allows the scanner to be configured around different workstation workflows.

For example, trigger mode may suit mobile warehouse use, while auto-sensing may be useful when the scanner remains in its stand.

Offline Data Storage

Some documented DS6510B configurations support storage mode so barcode records can be captured when the scanner is temporarily outside communication range.

The source material supplied for this product identifies approximately 350 KB / over 20,000 product-code records for one DS6510B configuration, while other third-party listings show different storage capacities.

For this reason, NEOTECH® does not recommend advertising a fixed barcode-storage count unless the exact firmware and supplied configuration are confirmed.

Battery

The supplied DS6510B specification identifies a rechargeable battery rated at approximately:

Battery Capacity: 2200 mAh

Charging Time: Approximately 6.5 hours under the supplier's stated conditions

Supplier-Stated Continuous Operation: ≥20 hours under defined conditions

Battery runtime should not be treated as guaranteed.

Actual operating time depends on:

• Scan frequency
• Wireless mode
• Standby periods
• Beeper and indicator usage
• Battery age
• Environmental conditions

Technical Specifications

Primary Model: DS6510B / DS6510B-2D

OEM / Alternate Reference: PT-R6510B

Product Type: Wireless Handheld 1D/2D Barcode Scanner

Scan Technology: CMOS Area Imager

Sensor Resolution: 640 × 480

CPU: 32-bit

Light Source: LED aiming / illumination system

Communication: USB, 2.4 GHz Wireless, Bluetooth 4.2

Scan Modes: Manual Trigger, Auto Sense, Continuous

2D Barcode Support: QR Code, Data Matrix, PDF417 and other compatible formats

1D Barcode Support: UPC/EAN, Code 128, Code 39, Code 93, GS1 and other compatible formats

Wireless Range – 2.4 GHz: Up to approximately 100 m under open conditions according to documented DS6510B specifications

Bluetooth Range: Up to approximately 30 m under open conditions according to supplier documentation

Battery: Approximately 2200 mAh on the supplied DS6510B specification

Scanner Dimensions: Approximately 60 × 115 × 170 mm on the supplied configuration

Scanner Weight: Approximately 160 g excluding cable according to supplied specification

Charging Stand: Included/available depending on exact package configuration

Specifications should be confirmed against the actual DS6510B / PT-R6510B unit being supplied because OEM configurations and firmware can vary.

Charging Stand

The DS6510B is commonly supplied as a wireless scanner with a charging stand.

The stand provides a fixed location for the scanner when it is not being used.

It may also support a presentation-style workflow where compatible barcodes are brought to the scanner while auto-sensing mode is enabled.

Exact charging and communication functionality should be verified for the supplied stand.

Warehouse & Inventory Applications

The scanner may be suitable for:

• Inventory counting
• Stock receiving
• Order picking
• Product identification
• Warehouse transfers
• Asset tracking
• Goods dispatch
• Stock verification

Wireless operation allows employees to move around a work area without remaining physically attached to a computer through the scanner cable.

Retail Applications

Potential retail uses include:

• POS barcode scanning
• Stock counting
• Price checking
• Product lookup
• Back-office inventory
• Goods receiving

POS compatibility depends on the operating system and POS application being used.

Logistics & Distribution

The DS6510B may also be considered for:

• Shipment processing
• Parcel identification
• Dispatch
• Order verification
• Warehouse staging
• Distribution-centre workflows

For courier or transportation applications requiring specialised postal or logistics barcode formats, exact symbology support should be verified first.

Screen Barcode Reading

2D area-imaging technology allows the scanner to read compatible codes displayed electronically.

This can be useful for:

• QR codes
• Electronic order references
• Digital loyalty codes
• Electronic tickets
• Mobile application barcodes

It does not mean the scanner is automatically compatible with every payment, ticketing or mobile application.

Connectivity & Compatibility

The scanner may be used with compatible devices through:

• USB
• Bluetooth
• 2.4 GHz receiver

Supplier information mentions Windows, Android, Linux/Ubuntu and other host environments across different DS6510B implementations.

However, NEOTECH® does not claim universal operating-system compatibility.

Before deployment, verify:

• Operating system
• USB HID requirements
• Bluetooth profile
• POS software
• ERP/WMS application
• Required keyboard language
• Barcode symbologies
• Data formatting requirements

Multilingual Data Output

The supplied DS6510B specification describes configurable multilingual output for certain environments, including languages such as:

• English
• Russian
• Japanese
• Chinese
• Korean
• Thai

It also describes configurable character insertion and replacement functions.

Because keyboard layout and character handling depend on the host operating system and scanner configuration, multilingual requirements should be tested with the actual business application before wider deployment.

DS6510B and PT-R6510B Model Reference

For search and replacement purposes, this page references both:

DS6510B
and
PT-R6510B

The DS6510B / DS6510B-2D designation is independently documented in available supplier/manufacturer-channel sources.

PT-R6510B is retained as the OEM/alternate model reference supplied for this product.

NEOTECH® does not claim that PT-R6510B is an official manufacturer cross-reference unless supported by the actual supplier documentation, packaging or product label.

This approach helps customers searching either model reference without misrepresenting the relationship between the two identifiers.

Things to Verify Before Ordering

Please confirm:

• DS6510B / DS6510B-2D or PT-R6510B reference
• 1D and 2D barcode requirements
• Required barcode symbologies
• USB requirement
• 2.4 GHz wireless requirement
• Bluetooth requirement
• Host operating system
• POS / ERP / WMS compatibility
• Offline storage requirement
• Required wireless range
• Keyboard language
• Charging stand requirement
• Battery configuration
• Package contents

For specialised workflows, sending a sample barcode for testing is preferable to assuming compatibility from the barcode name alone.

Purpose of Use

The DS6510B / PT-R6510B is intended to provide flexible barcode data capture where a business wants a handheld scanner capable of working through wired USB or wireless communication.

A typical warehouse workflow may be:

Barcode → Scanner → 2.4 GHz / Bluetooth / USB → Computer or POS → Business Application

The scanner captures barcode information; inventory, POS, ERP or warehouse-management functions are provided by separate software.

Why Choose NEOTECH® UAE

NEOTECH® supplies barcode and automatic-identification hardware for business applications within the UAE.

We can assist with:

• 1D versus 2D scanner selection
• Wireless scanner requirements
• Barcode symbology review
• USB / Bluetooth / 2.4 GHz selection
• Warehouse scanner requirements
• POS scanner requirements
• Sample barcode compatibility checks
• Related barcode and data-capture equipment

Learn First. Decide Second. Buy Only If It Is Right for Your Needs.

There is absolutely no obligation or pressure to proceed with the purchase with us.

Delivery — UAE

NEOTECH® supplies within the United Arab Emirates.

Shipping: Free Standard Shipping
Order Cut-Off: 2:00 PM GST
Handling: 1–2 business days
Transit: 3–5 business days
Estimated Total Delivery: 4–7 business days

Stock and exact scanner configuration should be confirmed before placing a time-sensitive order.

FAQ - DS6510B and PT-R6510B

Q: Are DS6510B and PT-R6510B the same barcode scanner?
A: DS6510B / DS6510B-2D is the documented scanner model used for this product platform. PT-R6510B is retained on this page as an OEM/alternate model reference supplied with the product information. The exact model marking should be confirmed from the unit or packaging before ordering.

Q: Can the DS6510B scan QR codes and normal 1D barcodes?
A: Yes. Documented DS6510B configurations support common 1D barcodes together with 2D formats including QR Code, Data Matrix and PDF417. Specialised barcode formats should be verified before deployment.

Q: Is the DS6510B a Wi-Fi barcode scanner?
A: It is more accurate to describe it as a scanner with USB, Bluetooth 4.2 and dedicated 2.4 GHz wireless communication. The 2.4 GHz connection uses a compatible wireless receiver and should not automatically be described as conventional Wi-Fi network connectivity.
