5-Port Industrial Unmanaged Ethernet Switch W/4*10/100Tx + 1*100Fx (SC) Multi-Mode 2Km; EOT (-40 to 75C)

Unmanaged 5-Port Industrial Ethernet Switch with 100Fx SC fiber uplink, 2Km range, and wide temp support. Ideal for harsh networks. Buy now at NEOTECH UAE.

✅ Overview

Engineered for extreme temperatures and rugged deployments, this 5-Port Industrial Ethernet Switch features 4 copper ports and 1 SC-type fiber port. Supporting a multi-mode transmission range of up to 2Km, it ensures rock-solid performance in outdoor and factory settings. Perfect for long-range connectivity without signal degradation.

✅ Product Description

This 5-port unmanaged industrial Ethernet switch provides a compact, rugged networking solution ideal for factory automation, transportation, and outdoor monitoring. It offers 4 x 10/100 Mbps RJ45 ports and 1 x 100 Mbps SC fiber uplink (multi-mode, 2Km).

With extended operating temperatures (-40°C to 75°C) and electro-optical transmission, it handles harsh conditions where commercial switches fail. The plug-and-play setup makes it perfect for edge network deployments, remote cameras, and control systems needing long-distance data transmission with fiber optics.

✅ Key Features

• 4× 10/100Base-TX RJ45 Ethernet Ports

• 1× 100Base-FX SC Multi-Mode Fiber Port (2Km)

• Wide temp operation: -40°C to 75°C

• No configuration required—true plug-and-play

• Surge and ESD protection for field use

• Rugged fanless metal design

• DIN-rail or wall-mount ready

✅ Specifications

• Copper Ports: 4 x 10/100Base-TX (Auto-Negotiation)

• Fiber Uplink: 1 x 100Base-FX SC Multi-Mode (1310nm, 2Km)

• Switching Capacity: 1 Gbps

• Forwarding Rate: 0.744 Mpps

• Operating Temp: -40°C to 75°C

• Input Voltage: 12–48V DC

• Housing: Industrial-grade aluminum alloy

• Mounting: DIN-rail or wall-mount

• Dimensions: Approx. 110mm x 80mm x 30mm

✅ Supported OS/Application/Industries

• OS Compatibility: OS-independent

• Applications: Fiber uplinks for surveillance, SCADA, or industrial IoT

• Industries: Oil & Gas, Railways, Renewable Energy, Smart Cities, Utilities

✅ Benefits & Compatibility

• Ideal for long-distance fiber-to-copper bridging

• Plug-and-play ease for non-tech installations

• Fiber SC port supports up to 2Km transmission

• Vibration-resistant, maintenance-free design

• Wide voltage & temperature tolerance ensures uptime

✅ Purpose of Use

Designed to bridge copper-based control networks to long-distance fiber uplinks, it’s a reliable switch for remote industrial field devices or edge data nodes in smart grids.

✅ How to Use

1. Mount the switch on DIN-rail or wall

2. Connect 10/100 devices to RJ45 ports

3. Link fiber cable to SC port for uplink

4. Power via 12–48V DC input

5. Run instantly—no setup required

✅ Packaging/Weight/Dimension

• Dimensions: 110 x 80 x 30 mm

• Weight: ~0.4 kg

• In the Box: Switch unit, power terminal block, mounting accessories, user manual

✅ Warranty and FAQs

Warranty: 12-month limited replacement
FAQs:
Q1: Is this switch managed?
A1: No, it’s completely unmanaged.
Q2: Can the SC fiber port connect to a switch with LC?
A2: You’ll need an SC-to-LC adapter or matching transceiver.
Q3: Does it support PoE?
A3: No, this model does not have PoE.

✅ Performance, Quality, Durability, and Reliability

With stable fiber performance over 2 kilometers and ESD/EMI resilience, this switch outperforms standard gear in high-vibration, high-temperature, and mission-critical environments.

✅ Best Price Guarantee

Buy with confidence. We offer the most competitive price in the UAE. Find it lower elsewhere? We'll match it.

✅ Shop Today & Receive Your Delivery Across the UAE!

Order now for fast delivery to Dubai, Abu Dhabi, Sharjah, and across all UAE regions. NEOTECH ensures reliable, safe, and timely shipping.

✅ Request for Customer Reviews and Testimonials

Used this model in a remote deployment? Share your story and help others trust reliable fiber-based industrial connectivity.

✅ After Sales Support

From setup advice to warranty service, we’ve got you. Our support team is here to help you maximize performance and uptime.

✅ Get in Touch

Need fiber connectivity guidance or help choosing the right switch? Contact our team today. We’re just a message or call away.

✅ Stock Availability

We work hard to maintain real-time inventory. For bulk or urgent orders, contact us directly to confirm availability.

✅ Disclaimer

Specs and visuals may change without notice. Verify details with our team before ordering. Product is for general information only and may vary slightly.
