NEOTECH
UNION 60A 2025 ECB Approved CIS Money Counter with Bill Printing Function
Couldn't load pickup availability
Compact UNION 60A counts mixed euros with CIS/UV/MG/IR scans, dual-tray sort & 1,000 n/min on 4″ LED—ECB-approved, ultra-portable.
Overview
Meet the UNION 60A 2025 ECB Approved CIS Cash Counter & Detector. Its Contact Image Sensor (CIS) plus UV, magnetic-ink and IR checks nail fakes, dual-tray sorting splits legits vs. rejects, and it zips through 1,000 notes/min on a crisp 4″ LED display—perfect for ATMs, kiosks, back-offices.
Product Description
Load 300–500 mixed euros into the compact hopper, tap Start, and chill—UNION 60A handles the rest. CIS captures each bill’s image; UV/MG/IR sensors authenticate in real time. Clean notes drop to Tray 1; rejects to Tray 2. Built in a rugged steel frame with a whisper-quiet motor (< 60 dB), it delivers nonstop reliability. Export logs or update firmware via USB 2.0/RS-232.
Key Features
-
CIS Imaging + 3-Sensor Security (CIS, UV, MG & IR)
-
ECB-Approved 2025 for euro note trust
-
1,000 n/min high-speed counting
-
Dual-Tray Sorting: legit vs. reject pockets
-
4″ LED Display: live counts, modes & alerts
-
Modes: Count, Batch, Add, Auto-Stop
-
Capacity: 300-note hopper │150-note stacker │50-note reject
-
Connectivity: USB 2.0 & RS-232 for logs & firmware
-
Quiet & Compact: steel-frame chassis, low-noise motor
Specifications
| Spec | Detail |
|---|---|
| Model | UNION 60A CIS |
| Counting Speed | Up to 1,000 notes/min |
| Hopper Capacity | 300 notes |
| Stacker Capacity | 150 notes |
| Reject Tray Capacity | 50 notes |
| Detection Methods | CIS, UV, MG, IR |
| Display | 4″ LED real-time panel |
| Modes | Count, Batch, Add, Auto-Stop |
| Connectivity | USB 2.0, RS-232 |
| Power | AC 100–240 V, 50/60 Hz |
| Dimensions (W×D×H) | 260 × 180 × 200 mm |
| Weight | 4.5 kg |
Supported Use Cases
-
ATM & kiosk cash-in-transit verification
-
Retail pop-up tills & kiosks
-
Small back-office cash rooms
-
Event ticketing booths
-
Corporate reception & finance desks
Benefits & Compatibility
-
Space-Saving Design: fits any counter
-
Bank-Grade Security: CIS + UV/MG/IR scans
-
Rush-Ready: handles 1,000 n/min throughput
-
Whisper-Quiet: < 60 dB motor noise
-
Easy Reporting: USB/RS-232 export
Purpose of Use
Built for tight-space, euro-focused workflows—automate sorting, detection & counting so your team stays fast and focused.
How to Use
-
Plug into AC & connect USB/RS-232
-
Load up to 300 mixed euros into hopper
-
Select mode on the LED panel (Count/Batch/Add)
-
Press Start → auto-feed, scan & sort
-
Grab legits from Tray 1; rejects from Tray 2
Packaging / Weight / Dimensions
-
Includes: unit, power cord, USB & RS-232 cables, manual, cleaning brush
-
Carton Size: 300 × 220 × 240 mm
-
Gross Weight: ~ 5.5 kg
Warranty & FAQs
-
1-Year Limited Warranty
-
Remote Support: phone & email
-
On-Site Service: available
FAQs
-
Q: Detects polymer notes?
A: Optimized for euro paper series. -
Q: Adjustable batch size?
A: Up to 200 notes per batch.
Performance, Quality & Reliability
ECB-approved with < 0.01 % error. Industrial motor and precision sensors ensure bulletproof accuracy shift after shift.
Best Price Guarantee
Spotted a lower UAE price? We’ll match it—shop confidently with NEOTECH.
Shop Today & Delivery Across UAE
Order now for tracked 24–48 hr delivery to Dubai, Abu Dhabi, Sharjah & beyond—securely packaged.
Request Customer Reviews
Tried the Mini 60A CIS? Drop a quick review to help peers pick the right counter.
After-Sales Support
Need firmware updates or troubleshooting? Our experts are live via chat, phone or email—24/7.
Get in Touch
Bulk orders or integration questions? Reach us at neodgital.com/pages/contact.
Stock Availability
High demand—confirm stock before ordering to secure yours.
Disclaimer
All info is general and may change without notice. Images are illustrative. Always verify specs, pricing & stock with our sales team before purchase.
