Windson WNI-6223B-USB 2D Wireless Handheld Long Range Barcode Scanner
Couldn't load pickup availability
RF433 wireless 2D/1D scanner: 50 m range, scans QR/DM/1D up to 450 mm, USB dongle, 120 fps, 80 000 scans battery, IP54 rugged.
Overview
The Windson WNI-6223B-USB is a cordless 2D CMOS imager built for insane range. It decodes QR, DataMatrix, PDF417 plus all 1D codes from 30 mm to 450 mm away. Plug in the RF433 USB dongleโno drivers. Perfect for high-bay warehouses, retail floors, and mobile POS.
Product Description
Compact powerhouse, epic reach:
-
2D CMOS Engine: 640ร480 px @ 120 fps for blur-free scans
-
Symbologies: QR, DataMatrix, PDF417, Aztec + UPC/EAN, Code 128/39
-
Scan Range: 30 mmโ450 mm on 20 mil codes
-
Wireless Link: RF433 USB dongle, up to 50 m line-of-sight
-
Battery Life: 1 000 mAh Li-ion delivers ~80 000 scans/charge
-
Speed: 120 scans/sec in auto or trigger mode
-
Rugged Build: IP54 dust/water spray resistant; 1.5 m drop-proof
-
Modes: HID-Keyboard & Virtual COM (HID-VCOM)
Scan aisles or docksโno cables, no sweat.
Key Features
-
Ultra-Long Range: RF433 link covers 50 m LOS
-
Multi-Code Support: 2D & 1D in one handheld
-
High-Speed Capture: 120 fps for peak efficiency
-
All-Day Battery: 80 000+ scans per full charge
-
Rugged & Reliable: IP54 & drop-resistant design
-
Plug-&-Play: Instant pairing via USB dongle
Specifications
| Spec | Detail |
|---|---|
| Sensor | CMOS 640ร480 @ 120 fps |
| Decode Types | 2D (QR, DM, PDF417, Aztec) + 1D (UPC/EAN, Code) |
| Range | 30โ450 mm (@ 20 mil PCS 90) |
| Wireless | RF433 USB dongle (โค 50 m LOS) |
| Battery | 1 000 mAh Li-ion; ~80 000 scans/charge |
| Interface Modes | HID-Keyboard; Virtual COM (HID-VCOM) |
| Ingress Rating | IP54 |
| Drop Resistance | 1.5 m |
| Trigger | Auto-sense & manual button |
| Dimensions | 160ร60ร40 mm |
| Weight | ~100 g (with battery) |
| Operating Temp. | โ10 ยฐC to 50 ยฐC |
Supported Platforms & Use Cases
-
OS: Windows, macOS, Linux, Android, iOS
-
Use Cases: High-bay warehousing, retail scanning, stock audits, mobile POS
Benefits & Compatibility
-
Cable-Free Flex: Wide-area scanning with RF433 tech
-
Rapid Throughput: 120 fps keeps workflows flowing
-
Built Tough: Dust/spray-proof + drop-resistant for daily use
-
Universal Fit: Works with any barcode system
-
Easy Setup: Plug-in dongleโinstant pairing
Purpose of Use
Ideal for warehouse aisles, cross-dock ops, retail expanses, and any environment needing long-reach scanning.
How to Use
-
Charge via USB-C.
-
Plug RF433 dongle into your host.
-
Aim and scanโauto or press trigger.
-
Watch data appear instantly.
Packaging & Dimensions
-
Includes: Scanner, RF433 USB dongle, USB-C cable, quick-start guide
-
Product Size: 160ร60ร40 mm
-
Weight: ~100 g
Warranty & FAQs
Warranty: 1 year limited.
FAQs:
-
Q: Can it read reflective barcodes?
A: Yesโauto-exposure handles glare. -
Q: How to switch modes?
A: Scan the mode-switch QR in the guide.
Performance & Reliability
Industrial-grade optics deliver >99 % decode accuracy. Firmware updates via USB keep it future-ready. Rated for 8 hrs continuous use.
