20–82.5 mm OEM thermal ticket printer for kiosk integration with RS232, USB and Ethernet interfaces

The CUSTOM KPM302III is an embedded thermal ticket printer designed for OEM kiosk integration and heavy-duty applications.

It supports ticket widths from 20 mm to 82.5 mm and combines thermal printing, automatic cutting, multiple media sensors and RS232, USB and Ethernet connectivity within a compact mechanism designed for integration into self-service equipment.

Depending on the selected configuration, the KPM302III platform can also support RFID functionality, multiple SAM management and an internal barcode scanner, making configuration verification important before ordering.

Key Features

• OEM thermal ticket printer
• Designed for heavy-duty applications
• Ticket width from 20 to 82.5 mm
• 200/300 dpi configurations
• Printing speed around 200 mm/sec or higher depending on configuration/mode
• Direct thermal printing with fixed print head
• RS232 interface
• USB interface
• Ethernet interface
• Automatic cutter
• Cutter reliability rated at over 2,000,000 cuts in the supplied manufacturer material
• 1D and 2D barcode printing
• QR Code printing
• PDF417 support
• Data Matrix support
• Aztec support
• Fan-fold and paper-roll handling
• Four-position black-mark sensor
• Gap/hole-mark sensor configurable through software
• Ticket-presence sensor
• True Font character support
• 32-bit processing
• RFID versions with multiple SAM management
• Internal barcode-scanner configuration available

Technical Specifications

Brand: CUSTOM

Product Family: KPM302 / KPM302III

Model Focus: KPM302III

Product Type: OEM kiosk thermal ticket printer

Printing Method: Thermal with fixed print head

Standard Resolution: 203 dpi / 8 dots per mm on the referenced configuration

Alternative Resolution: 300 dpi configuration available

Printing Speed: 200 mm/sec high-speed mode

Normal Printing Mode: 170 mm/sec

High-Quality Printing Mode: 110 mm/sec

Ticket/Paper Width: 20–82.5 mm depending on configuration

Paper Weight: 80–255 g/m²

Maximum Roll Diameter: 300 mm

Interfaces: RS232 / USB / Ethernet

Data Buffer: 32 kB

Flash Memory: 16 MB

Graphic Memory: Up to 1 MB for dynamic logo management

Power Supply: 24 VDC ±10%

Average Consumption: Approximately 0.8 A under the stated manufacturer's test condition

Print Head Life: 100 km / 100 million pulses

Cutter: More than 2,000,000 cuts stated in the supplied manufacturer material

Operating Temperature: 0°C to +50°C

Dimensions: 191 × 123 × 160 mm

Weight: Approximately 3.5 kg

Supported Barcode Printing

The KPM302III platform supports printing of commonly used 1D and 2D barcode formats.

1D: UPC-A, UPC-E, EAN-13, EAN-8, Code 39, ITF, Codabar, Code 93, Code 128 and Code 32.

2D: PDF417, Data Matrix, Aztec and QR Code.

This can be useful for ticketing applications where machine-readable transaction, validation or identification information must be printed directly onto the issued media.

RFID Version

RFID-enabled KPM302III configurations support multiple SAM management.

This makes the RFID version relevant to applications involving compatible contactless ticketing, identification or validation workflows.

Important: RFID should not be assumed to be included with every KPM302III. Confirm the exact printer configuration, RFID technology and system requirements before ordering.

Internal Barcode Scanner

The manufacturer material also identifies an internal barcode scanner for applications such as card validation and fraud-prevention workflows.

This functionality is configuration-dependent and should be confirmed for the exact unit required.

Media Handling

The KPM302III supports both fan-fold media and paper-roll configurations, making the platform adaptable to different kiosk designs.

Media detection capabilities include:

• Four-position black-mark sensing
• Gap/hole-mark sensing configurable through software
• Ticket-presence sensing

The exact media dimensions, thickness, sensor position and ticket format should be verified during kiosk integration.

Applications

The CUSTOM KPM302III may be considered for:

• Self-service kiosks
• Ticketing kiosks
• Transportation ticketing
• Parking terminals
• Railway and metro ticketing
• Airport self-service equipment
• Queue-management terminals
• Access and validation systems
• OEM vending and unattended terminals
• RFID-enabled ticketing systems

Suitability depends on the complete kiosk design and required KPM302III configuration.

Purpose of Use

The KPM302III is primarily intended to function as an embedded printing mechanism within an OEM system, rather than as a conventional desktop receipt printer.

It can provide ticket or receipt output while the surrounding kiosk controls the user interface, transaction processing and associated application workflow.

Compatibility

System compatibility should be evaluated according to:

• Host operating system
• RS232, USB or Ethernet interface
• Printer driver
• Application software
• Required emulation
• Ticket dimensions
• Media characteristics
• Cutter requirements
• RFID requirements
• Barcode-scanner requirements
• Power supply
• Mechanical mounting and clearance

Do not select an OEM printer solely by its external dimensions or model-family name.

Things to Verify Before Ordering

Please confirm the following before purchasing:

• Exact KPM302III part/configuration
• 203 dpi or 300 dpi requirement
• Required ticket width
• Paper weight and media type
• Roll or fan-fold media
• RS232, USB or Ethernet interface requirement
• RFID required or not required
• Required RFID technology
• SAM requirements
• Internal barcode scanner required or not
• Cutter configuration
• Sensor requirements
• Host operating system
• Driver/application compatibility
• Available 24 VDC power
• Physical mounting space

This verification is especially important for OEM equipment because two printers from the same product family may not have identical options.

Who Should Consider the CUSTOM KPM302III?

The KPM302III may be appropriate for organizations already designing or maintaining:

• Self-service terminals
• Ticketing machines
• Transportation systems
• Parking equipment
• RFID ticketing systems
• Automated kiosks
• Embedded OEM equipment

For replacement requirements, providing the existing printer label, complete part number and photographs of the interfaces can help identify the required configuration.

Why NEOTECH® UAE

NEOTECH® takes an education-first approach to OEM hardware.

For a configurable product such as the CUSTOM KPM302III, our priority is to help customers identify the required model, interface, resolution, media and optional functionality before proceeding.

Learn First. Decide Second. Buy Only If It Is Right for Your Needs.

There is absolutely no obligation or pressure to proceed with the purchase with us.

FAQ - CUSTOM KPM302III RFID Kiosk

Q: What is the CUSTOM KPM302III?
A: It is an embedded thermal ticket printer designed for OEM kiosk integration and applications requiring automated ticket or receipt output.

Q: What ticket width does the KPM302III support?
A: The manufacturer material supplied for this product family specifies ticket widths from 20 mm to 82.5 mm. Exact media compatibility should be checked against the selected configuration.

Q: Is the KPM302III a 203 dpi printer?
A: The referenced configuration specifies 203 dpi / 8 dots per mm. Manufacturer material also identifies 300 dpi configurations, so resolution should be confirmed before ordering.

Q: How fast does the CUSTOM KPM302III print?
A: Detailed information supplied lists 200 mm/sec in high-speed mode, 170 mm/sec in normal mode and 110 mm/sec in high-quality mode. Manufacturer overview material also describes printing above 200 mm/sec, which may depend on configuration and operating conditions.

Q: Does it support Ethernet?
A: Yes. RS232, USB and Ethernet interfaces are listed for the referenced KPM302III configuration.

Q: Can the KPM302III print QR codes?
A: Yes. QR Code is among the listed 2D barcode formats, together with PDF417, Data Matrix and Aztec.

Q: Does every KPM302III include RFID?
A: No such assumption should be made. RFID functionality is associated with specific versions/configurations and should be verified before ordering.

Q: Does it include an internal barcode scanner?
A: Manufacturer material identifies an internal barcode-scanner option/configuration. Confirm its inclusion for the exact unit being ordered.

Q: Is the KPM302III suitable as a direct replacement for my existing printer?
A: Possibly, but the model name alone is insufficient. Check the complete part number, resolution, interfaces, media, RFID configuration, power requirements and mechanical installation before replacement.
