Intelligent Banknote Deposit Processing for Secure Cash Automation

Professional Highlights

• SNBC BNE-S110M integrated cash deposit module
• Designed for compatible cash deposit terminals, kiosks and secure cash-handling systems
• Rated processing speed of 12 banknotes per second
• 500-note cash-in capacity
• 200-note escrow capacity
• 100-note rejection capacity
• Banknote counting with authentication
• Banknote fitness sorting and condition detection
• Serial number recognition functionality
• 5-inch touchscreen interface
• USB, serial and LAN communication interfaces
• Modular design for terminal integration and maintenance
• Supports multi-currency applications subject to installed currency software

Product Overview

The SNBC BNE-S110M is an integrated cash deposit module designed for automated banknote acceptance, authentication, counting and processing within compatible financial and self-service systems.

It provides a 500-note cash-in capacity, 200-note escrow capacity and 100-note rejection capacity to support controlled banknote deposit workflows.

Unlike a conventional standalone banknote counting machine, the BNE-S110M is intended for integration into a complete cash-handling solution with the necessary enclosure, host software, transaction controls and security arrangements.

Product Description

The SNBC BNE-S110M, manufactured by Shandong New Beiyang Information Technology Co., Ltd., is designed for financial automation and self-service cash deposit applications.

Its banknote-processing mechanism supports counting with authentication, fitness sorting and serial number recognition.

The module uses multiple detection methods to assess supported banknotes for authenticity and physical condition. Its published detection functions include identifying issues such as stains, tape, tears, missing corners, folded edges and double notes.

A 5-inch touchscreen provides an operator interface, while USB, serial and LAN communication ports support integration with compatible host systems.

The 200-note escrow section enables supported deposit workflows to temporarily hold banknotes before transaction completion, subject to the host application and system design.

For a complete deployment, customers must verify the selected currency configuration, supported note versions, terminal software, physical integration, security requirements and operational acceptance procedures.

Product Facts

Brand: SNBC / New Beiyang
Model: BNE-S110M
Product Type: Cash Deposit Module
Primary Function: Automated Banknote Deposit Processing
Rated Processing Speed: 12 Notes per Second
Cash-In Capacity: 500 Notes
Escrow Capacity: 200 Notes
Reject Capacity: 100 Notes
Display: 5-Inch Touchscreen
Authentication: Multi-Detection Banknote Verification
Additional Functions: Fitness Sorting and Serial Number Recognition
Communication: USB, Serial, LAN
Installation Type: Integrated Cash Deposit System
Currency Support: Subject to Installed Software and Configuration

Technical Specifications

Manufacturer: Shandong New Beiyang Information Technology Co., Ltd.
Brand: SNBC
Model: BNE-S110M
Equipment Category: Cash Deposit Module
Rated Processing Speed: 12 Notes per Second, Approximately 720 Notes per Minute
Cash-In Capacity: 500 Banknotes
Escrow Capacity: 200 Banknotes
Reject Slot Capacity: 100 Banknotes
Touchscreen Size: 5 Inches
Banknote Processing: Counting with Authentication
Sorting Function: Banknote Fitness Sorting
Serial Number Recognition: Supported
Banknote Condition Detection: Soil, Tape, Graffiti, Stain, Hole, Tear, De-Inking, Watermark, Missing Corner, Missing Edge, Dog-Ear and Double-Note Detection
Communication Interfaces: USB, Serial and LAN
Power Supply: 100–240V AC ±10%, 50/60Hz
Dimensions: 323 × 340 × 317 mm (W × D × H)
Installation: Integration into a Compatible Cash Deposit Terminal or Enclosure
Currency Software: Configuration-Dependent
Host Software: Required According to the Intended System
Warranty: Subject to Written Supplier Confirmation

Important: Processing speed, detection performance, supported currencies and operational functions depend on banknote condition, software, configuration and integration.

Applications

• Bank self-service cash deposit terminals
• Financial institution cash automation
• Automated cash acceptance kiosks
• Retail cash deposit systems
• Cash office automation projects
• Self-service financial terminals
• Secure cash collection systems
• Integrated cash-handling equipment

Compatibility

The SNBC BNE-S110M is intended for integration with compatible cash deposit terminals, kiosks and secure cash-handling systems.

Compatibility must be verified for:

• Supported banknote currencies and series
• Host application and communication protocols
• Deposit confirmation and cancellation workflows
• Escrow and rejection handling
• Terminal enclosure and mechanical mounting
• Power supply and electrical installation
• Security and access-control requirements
• Reporting, reconciliation and transaction logging
• Firmware and software support

The BNE-S110M should not be assumed to operate as a complete standalone banknote sorter without the required integration components.

Buyer Guidance

Before requesting a quotation, please confirm:

• Whether you require the BNE-S110M module or a complete cash deposit machine
• The country and intended installation location
• Required currencies and banknote series
• Whether AED banknotes are required
• Host system and software integration requirements
• Required cash-in, escrow and rejection workflows
• Physical installation dimensions and enclosure requirements
• Required communication interfaces
• Security, reporting and reconciliation requirements
• Quantity, configuration, warranty and delivery expectations

Important for UAE Customers: AED currency support must be confirmed for the exact software and firmware configuration before order acceptance. Multi-currency capability does not automatically mean every currency or banknote series is supported.

How to Use

1. Verify the required module configuration and supported currency software.
2. Install the module into a compatible terminal or approved enclosure.
3. Connect the required power and communication interfaces.
4. Configure the host application and transaction workflow.
5. Load or present supported banknotes according to the integrated system's operating procedure.
6. Allow the module to count, authenticate and process the banknotes.
7. Review rejected or suspect banknotes according to the organisation's procedures.
8. Complete deposit confirmation, reconciliation and transaction recording through the host system.
9. Follow the manufacturer's maintenance instructions for cleaning and inspection.

Professional integration and acceptance testing are required for many deployments.

Delivery & Returns UAE

Product availability, configuration, price, warranty and delivery lead time are subject to written confirmation before order acceptance.

The BNE-S110M is a specialised cash deposit module. A complete terminal, safe, enclosure, host software, currency licensing, installation, integration, training and maintenance services are not included unless expressly stated in the quotation.

Special-order conditions will be communicated before order acceptance.

Please verify the exact model, currency support, integration requirements, quantity, price, VAT, warranty and delivery terms before payment.

Returns and cancellations are subject to the agreed terms and applicable UAE consumer protection laws.

Why NEOTECH® UAE?

At NEOTECH® UAE, we believe in honest product information, transparent pricing, clear delivery terms and customer-first service.

We help customers understand the product's intended application, technical requirements and commercial conditions before purchasing.

If we accept your payment but cannot fulfil the agreed order, we will initiate a 100% refund of the amount received for the unfulfilled goods, including applicable VAT, without NEOTECH® cancellation or handling charges, subject to necessary payment verification and processing.

Learn First. Decide Second. No pressure, no obligation—just honest guidance to help you make an informed purchasing decision.

Contact – NEOTECH® UAE

NEOTECH® UAE
Operated by NEOLYN TECHNOLOGY LLC
Store 13, Computer Building, Al Fahidi, Bur Dubai, Dubai, UAE
Email: support@neotech.ae

For quotations, please mention SNBC BNE-S110M Cash Deposit Module, your required currency configuration and intended application.

FAQ – SNBC BNE-S110M

Q: What is the SNBC BNE-S110M?
A: It is an integrated cash deposit module designed for banknote counting, authentication, fitness sorting and deposit processing within compatible cash-handling systems.

Q: Is the BNE-S110M a standalone banknote sorting machine?
A: No. It is primarily designed as an integrated cash deposit module and may require a host terminal, software and other system components.

Q: What is its processing speed?
A: The manufacturer's current published specification is 12 notes per second, equivalent to approximately 720 notes per minute.

Q: How many banknotes can the input hold?
A: The specified cash-in capacity is 500 banknotes.

Q: What is the escrow capacity?
A: The escrow capacity is 200 banknotes.

Q: What is the reject capacity?
A: The reject slot holds up to 100 banknotes.

Q: Does it detect suspicious banknotes?
A: It provides multi-detection banknote authentication functions. No detection system should be treated as guaranteeing identification of every counterfeit or altered note.

Q: Does the BNE-S110M support AED currency?
A: AED support must be verified for the specific currency software and firmware supplied. It should not be assumed without written confirmation.

Q: Can it recognise banknote serial numbers?
A: Yes. Serial number recognition is among the manufacturer's listed functions.

Q: Does it support banknote fitness sorting?
A: Yes. The manufacturer lists fitness sorting and several banknote condition-detection functions.

Q: What communication interfaces are available?
A: USB, serial and LAN interfaces are listed.

Q: Does it include a complete cash deposit kiosk?
A: No. The module should not be assumed to include a complete kiosk, safe, enclosure or host software.

Q: Can NEOTECH® UAE provide software integration?
A: Any integration services must be separately assessed and expressly confirmed in writing.

Q: Is the BNE-S110M available in Dubai?
A: Please contact NEOTECH® UAE to confirm current sourcing availability, currency configuration, price, warranty and delivery terms.

Disclaimer – NEOTECH® UAE

SNBC, New Beiyang and associated product names are trademarks of their respective owners.

Specifications are based on published manufacturer information and may vary by hardware revision, software configuration and supported currency package.

Banknote authentication and fitness sorting functions are aids to cash processing and do not eliminate the need for appropriate financial controls and verification procedures.

NEOTECH® UAE does not claim manufacturer authorisation, banking-system certification or specialised integration capabilities unless independently confirmed.

Product images are illustrative. Availability, pricing, warranty, software, supported currencies, included components and delivery terms require written confirmation before order acceptance.
